Grooving process




We offer high quality grooving results and multiple grooves

Grooving technology cuts a spiral grooves on the internal shapes of punching die, a wheel hub with grooves and etc. With grooving technology, we create the straight grooves on the shaft and hub so that it fits together. We achieve flatness of 0,02 mm per 1 m. The grooving process creates a wide range of grooves, which is suitable if you need connection with various pier.








Flatness of 0,02 mm

We achieve flatness of 0,02 mm per 1 m. Due to new and well maintained machines, flatness and parallelism is achieved. In normal conditions flatness of 0.1 to 0.2 mm per 1 m is achieved. The production of continuous grooves in the range from 4 to 40 mm.







Advantages of metal grooving at IMC Slovakia








The accuracy of dimensional production is our number one priority.





Technique accuracy


We use the highest quality equipment such as grooving machines.





Top quality employees


Grooving technology performs by skilled employees.




contact us







Technical specification of metal grooving


  • Groove width: 50 mm
  • Towing length: 800 mm
  • Tractive force: 21 N
  • Workpiece weight: 20 kg
  • Power consumption: 7,5 kW
  • Continuous regulation: 0 – 25 m/min
  • Reverse mode: 40 m/min
  • The diameter of a hole: 10 - 330 mm
  • Movement: 0 - 5, 0 mm
  • Accuracy: ± 0,1 mm
  • Work desk dimension: 500 x 750 mm
  • Space requirement: 1,2 x 2,3 mm
